    Anode for Industrial
    Anode for Industrial

    Giá: Liên hệ

      Mã sản phẩm: CM- IDT
    • Hãng sản xuất : Impalloy
    • Bảo hành : 24 Tháng
    • Tình trạng: Sản xuất theo yêu cầu của khách hàng

    Industrial

    C-Sentry sacrificial anodes have been used to protect tanks, onshore pipelines, intake screens, water processing units, in short anywhere that steel is in contact with water.

    C-Sentry Zinc and Aluminium rod is available in a variety of diameters.

    In salt water Aluminium or Zinc are commonly used, whereas in fresh or brackish low resistivity water, Magnesium is used.

    Impalloy Limited have extensive experience in designing cathodic protection systems for tanks etc. We can supply anodes from our C-Sentry range of standard flush mounted designs or prepare special anodes to support your requirements.

    Contact us to discuss your requirements and the ways in which we help minimise costs while maximising on protective life.

    C-Sentry Zinc Rods

    Anode Type Overall Dimensions (mm) Weight (kg)
    Length Diameter Gross
    20ZR500 500 20 1.12
    25ZR500 500 25 1.74
    30ZR500 500 30 2.51
    34ZR500 500 34 3.22
    40ZR500 500 40 4.46
    50ZR500 500 50 6.97
    60ZR500 500 60 10.04
    70ZR500 500 70 13.67
    80ZR500 500 80 7.85
    90ZR500 500 90 22.60
    100ZR500 500 100 27.90
    150ZR500 500 150 62.77
    170ZR250 250 170 40.31



    C-Sentry Aluminum Rods

    Anode Type Overall Dimensions (mm) Weight (kg)
    Length Diameter Gross
    20ZR500 500 20 1.12
    25ZR500 500 25 1.74
    30ZR500 500 30 2.51
    34ZR500 500 34 3.22
    40ZR500 500 40 4.46
    50ZR500 500 50 6.97
    60ZR500 500 60 10.04
    70ZR500 500 70 13.67
    80ZR500 500 80 7.85
    90ZR500 500 90 22.60
    100ZR500 500 100 27.90
    150ZR500 500 150 62.77
    170ZR250 250 170 40.31
